14 Transfer protocol
Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.
14 Temp. thresholdV 1: Switching out-
put
Output R-CT [1.1] DPT_Switch 1 Bit
15 Temp. thresholdV 1: Switching out-
put block
Input -WC- [1.2] DPT_Bool 1 Bit
16 Temp. thresholdV 2: Absolute value Input /
Output
RWC
T
[9.1] DPT_-
Value_Temp
2 Bytes
17 Temp. thresholdV 2: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit
18 Temp. thresholdV 2: Switching
delay from 0 to 1
Input -WC- [7.5] DPT_TimePeri-
odSec
2 Bytes
19 Temp. thresholdV 2: Switching
delay from 1 to 0
Input -WC- [7.5] DPT_TimePeri-
odSec
2 Bytes
20 Temp. thresholdV 2: Switching out-
put
Output R-CT [1.1] DPT_Switch 1 Bit
21 Temp. thresholdV 2: Switching out-
put block
Input -WC- [1.2] DPT_Bool 1 Bit
22 Temp. thresholdV 3: Absolute value Input /
Output
RWC
T
[9.1] DPT_-
Value_Temp
2 Bytes
23 Temp. thresholdV 3: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit
24 Temp. thresholdV 3: Switching
delay from 0 to 1
Input -WC- [7.5] DPT_TimePeri-
odSec
2 Bytes
25 Temp. thresholdV 3: Switching
delay from 1 to 0
Input -WC- [7.5] DPT_TimePeri-
odSec
2 Bytes
26 Temp. thresholdV 3: Switching out-
put
Output R-CT [1.1] DPT_Switch 1 Bit
27 Temp. thresholdV 3: Switching out-
put block
Input -WC- [1.2] DPT_Bool 1 Bit
29 Temp.control: HVAC mode (prio-
rity 1)
Input /
Output
RWC
T
[20.102] DPT_HVAC-
Mode
1 Byte
30 Temp.control: HVAC mode (prio-
rity 2)
Input /
Output
RWC
T
[20.102] DPT_HVAC-
Mode
1 Byte
31 Temp.control: Mode frost/heat pro-
tection activt.
Input /
Output
RWC
T
[1.1] DPT_Switch 1 Bit
32 Temp.control: Block (On when
value = 1)
Input -WC- [1.1] DPT_Switch 1 Bit
33 Temp.control: Current setpoint Output R-CT [9.1] DPT_-
Value_Temp
2 Bytes
34 Temp.control: Switch. (Heating = 0 |
Cooling = 1)
Input -WC- [1.1] DPT_Switch 1 Bit
35 Temp.control: Setpoint Comfort
heating
Input /
Output
RWC
T
[9.1] DPT_-
Value_Temp
2 Bytes
36 Temp.control: Setpoint Comfort
heat.(1:+ | 0:-)
Input -WC- [1.1] DPT_Switch 1 Bit
37 Temp.control: Setpoint Comfort
cooling
Input /
Output
RWC
T
[9.1] DPT_-
Value_Temp
2 Bytes
No Text Function Flags DPT type Size
