13 Transfer protocol
Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.
7. Transfer protocol
Units:
Temperatures in degrees Celsius
Air humidity in %
Absolute air humidity in g/kg and/or g/m
3
VOC content in ppm
Variables in %
7.1. List of all communications objects
Abbreviation flags:
C Communication
R Read
WWrite
T Transfer
UUpdate
No Text Function Flags DPT type Size
0 Software version readable R-CT [217.1] DPT_Version 2 Bytes
1 Malfunction temperature/humidity
sensor
Output R-CT [1.1] DPT_Switch 1 Bit
2 VOC sensor malfunction Output R-CT [1.1] DPT_Switch 1 Bit
3 External measured value for tempe-
rature
Input -WC- [9.1] DPT_-
Value_Temp
2 Bytes
4 Internal measured value for tempe-
rature
Output R-CT [9.1] DPT_-
Value_Temp
2 Bytes
5 Total measured value for tempera-
ture
Output R-CT [9.1] DPT_-
Value_Temp
2 Bytes
6 Request min./max. temperature
measured value
Input -WC- [1.17] DPT_Trigger 1 Bit
7 Minimum measured value for tem-
perature
Output R-CT [9.1] DPT_-
Value_Temp
2 Bytes
8 Maximum measured value for tem-
perature
Output R-CT [9.1] DPT_-
Value_Temp
2 Bytes
9 Reset min./max. measured value
for temperature
Input -WC- [1.17] DPT_Trigger 1 Bit
10 Temp. thresholdV 1: Absolute value Input /
Output
RWC
T
[9.1] DPT_-
Value_Temp
2 Bytes
11 Temp. thresholdV 1: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit
12 Temp. thresholdV 1: Switching
delay from 0 to 1
Input -WC- [7.5] DPT_TimePeri-
odSec
2 Bytes
13 Temp. thresholdV 1: Switching
delay from 1 to 0
Input -WC- [7.5] DPT_TimePeri-
odSec
2 Bytes
