43 Parameter setting

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

Switching output

The output switching delay can be set using objects or directly as a parameter.

Blocking

The switching output can be blocked using an object. Define specifications here for the

behaviour of the output when blocked.

The behaviour of the switching output on release is dependent on the value of the pa-

rameter "Switching output sends" (see "Switching output")

When the following conditions apply,

the output is

(TV = Threshold value)

• TV above = 1 | TV - hyst. below = 0

• TV above = 0 | TV - hyst. below = 1

• TV below = 1 |TV + hyst. above = 0

• TV below = 0 |TV + hyst. above = 1

Delays can be set via objects

(in seconds)

No • Yes

Switching delay from 0 to 1

for setting via objects:

valid until 1st communication

None • 1 s • 2 s • 5 s • 10 s • … • 2 h

Switching delay from 1 to 0

for setting via objects:

valid until 1st communication

None • 1 s • 2 s • 5 s • 10 s • … • 2 h

Switching output sends • on change

• on change to 1

• on change to 0

• on change and periodically

• on change to 1 and periodically

• on change to 0 and periodically

Send cycle

(is only sent if periodically is selected)

5 s • 10 s • 30 s… • 2 h

Use switching output block No • Yes

Analysis of the blocking object • At value 1: block | At value 0: release

• At value 0: block | At value 1: release

Blocking object value before first communi-

cation

0 • 1

Behaviour of the switching output

On block • Do not send message

• send 0

• send 1

On release

(with 2 seconds release delay)

[Dependent on the "Switching output

sends" setting]

Switching output sends on change • Do not send message

• Send switching output status

Switching output sends on change to 1 • Do not send message

• if switching output = 1  send 1

Switching output sends on change to 0 • Do not send message

• if switching output = 0  send 0
