21 Transfer protocol

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

208 Logic input 9 Input -WC- [1.2] DPT_Bool 1 Bit

209 Logic input 10 Input -WC- [1.2] DPT_Bool 1 Bit

210 Logic input 11 Input -WC- [1.2] DPT_Bool 1 Bit

211 Logic input 12 Input -WC- [1.2] DPT_Bool 1 Bit

212 Logic input 13 Input -WC- [1.2] DPT_Bool 1 Bit

213 Logic input 14 Input -WC- [1.2] DPT_Bool 1 Bit

214 Logic input 15 Input -WC- [1.2] DPT_Bool 1 Bit

215 Logic input 16 Input -WC- [1.2] DPT_Bool 1 Bit

220 Display contrast (1 = higher | 0 =

lower)

Input -WC- [1.1] DPT_Switch 1 Bit

221 Display lighting (1 = on | 0 = off) Input -WC- [1.1] DPT_Switch 1 Bit

222 Display lighting Brightness Input RWC

[5.1] DPT_Scaling 1 Byte

223 Display lighting Switch off delay Input RWC

[7.5] DPT_TimePeri-

odSec

2 Bytes

230 Date for display Input -WCT [11.1] DPT_Date 3 Bytes

231 Time for display Input -WCT [10.1] DPT_TimeOf-

Day

3 Bytes

232 8 bit object 1 for display Input -WC- [5] 5.xxx 1 Byte

233 8 bit object 2 for display Input -WC- [5] 5.xxx 1 Byte

234 8 bit object 3 for display Input -WC- [5] 5.xxx 1 Byte

235 16 bit object 1 for display Input -WC- [9] 9.xxx 2 Bytes

236 16 bit object 2 for display Input -WC- [9] 9.xxx 2 Bytes

237 Text message 1 for display Input -WC- [16.0]

DPT_String_ASCII

Bytes

238 Text message 2 for display Input -WC- [16.0]

DPT_String_ASCII

Bytes

239 Back jump release for display Input -WC- [1.1] DPT_Switch 1 Bit

240 Push button 1 long-term Output R-CT [1.8] DPT_UpDown 1 Bit

241 Push button 1 short-term Output R-CT [1.10] DPT_Start 1 Bit

242 Push button 1 switching Output R-CT [1.1] DPT_Switch 1 Bit

243 Push button 1 dimming Input /

Output

RWC

[3.7] DPT_Control_-

Dimming

4 Bit

244 Push button 1 encoder 8 bit Output R-CT [5] 5.xxx 1 Byte

245 Push button 1 encoder 16 bit Output R-CT [9] 9.xxx 2 Bytes

246 Push button 1 scene Output R-CT [5] 5.xxx 1 Byte

247 Push button 2 long-term Output R-CT [1.8] DPT_UpDown 1 Bit

248 Push button 2 short-term Output R-CT [1.10] DPT_Start 1 Bit

249 Push button 2 switching Output R-CT [1.1] DPT_Switch 1 Bit

250 Push button 2 dimming Input /

Output

RWC

[3.7] DPT_Control_-

Dimming

4 Bit

No Text Function Flags DPT type Size
