20 Transfer protocol

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

152 AND logic 1: Switching output

block

Input -WC- [1.2] DPT_Bool 1 Bit

153 AND logic 2: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit

154 AND logic 2: 8 bit output A Output R-CT [5] 5.xxx 1 Byte

155 AND logic 2: 8 bit output B Output R-CT [5] 5.xxx 1 Byte

156 AND logic 2: Switching output

block

Input -WC- [1.2] DPT_Bool 1 Bit

157 AND logic 3: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit

158 AND logic 3: 8 bit output A Output R-CT [5] 5.xxx 1 Byte

159 AND logic 3: 8 bit output B Output R-CT [5] 5.xxx 1 Byte

160 AND logic 3: Switching output

block

Input -WC- [1.2] DPT_Bool 1 Bit

161 AND logic 4: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit

162 AND logic 4: 8 bit output A Output R-CT [5] 5.xxx 1 Byte

163 AND logic 4: 8 bit output B Output R-CT [5] 5.xxx 1 Byte

164 AND logic 4: Switching output

block

Input -WC- [1.2] DPT_Bool 1 Bit

181 OR logic 1: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit

182 OR logic 1: 8 bit output A Output R-CT [5] 5.xxx 1 Byte

183 OR logic 1: 8 bit output B Output R-CT [5] 5.xxx 1 Byte

184 OR logic 1: Switching output block Input -WC- [1.2] DPT_Bool 1 Bit

185 OR logic 2: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit

186 OR logic 2: 8 bit output A Output R-CT [5] 5.xxx 1 Byte

187 OR logic 2: 8 bit output B Output R-CT [5] 5.xxx 1 Byte

188 OR logic 2: Switching output block Input -WC- [1.2] DPT_Bool 1 Bit

189 OR logic 3: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit

190 OR logic 3: 8 bit output A Output R-CT [5] 5.xxx 1 Byte

191 OR logic 3: 8 bit output B Output R-CT [5] 5.xxx 1 Byte

192 OR logic 3: Switching output block Input -WC- [1.2] DPT_Bool 1 Bit

193 OR logic 4: 1 bit switching output Output R-CT [1.1] DPT_Switch 1 Bit

194 OR logic 4: 8 bit output A Output R-CT [5] 5.xxx 1 Byte

195 OR logic 4: 8 bit output B Output R-CT [5] 5.xxx 1 Byte

196 OR logic 4: Switching output block Input -WC- [1.2] DPT_Bool 1 Bit

200 Logic input 1 Input -WC- [1.2] DPT_Bool 1 Bit

201 Logic input 2 Input -WC- [1.2] DPT_Bool 1 Bit

202 Logic input 3 Input -WC- [1.2] DPT_Bool 1 Bit

203 Logic input 4 Input -WC- [1.2] DPT_Bool 1 Bit

204 Logic input 5 Input -WC- [1.2] DPT_Bool 1 Bit

205 Logic input 6 Input -WC- [1.2] DPT_Bool 1 Bit

206 Logic input 7 Input -WC- [1.2] DPT_Bool 1 Bit

207 Logic input 8 Input -WC- [1.2] DPT_Bool 1 Bit

No Text Function Flags DPT type Size
