14 Transfer protocol

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

14 Temp. thresholdV 1: Switching out-

put

Output R-CT [1.1] DPT_Switch 1 Bit

15 Temp. thresholdV 1: Switching out-

put block

Input -WC- [1.2] DPT_Bool 1 Bit

16 Temp. thresholdV 2: Absolute value Input /

Output

RWC

[9.1] DPT_-

Value_Temp

2 Bytes

17 Temp. thresholdV 2: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit

18 Temp. thresholdV 2: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

19 Temp. thresholdV 2: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

20 Temp. thresholdV 2: Switching out-

put

Output R-CT [1.1] DPT_Switch 1 Bit

21 Temp. thresholdV 2: Switching out-

put block

Input -WC- [1.2] DPT_Bool 1 Bit

22 Temp. thresholdV 3: Absolute value Input /

Output

RWC

[9.1] DPT_-

Value_Temp

2 Bytes

23 Temp. thresholdV 3: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit

24 Temp. thresholdV 3: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

25 Temp. thresholdV 3: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

26 Temp. thresholdV 3: Switching out-

put

Output R-CT [1.1] DPT_Switch 1 Bit

27 Temp. thresholdV 3: Switching out-

put block

Input -WC- [1.2] DPT_Bool 1 Bit

29 Temp.control: HVAC mode (prio-

rity 1)

Input /

Output

RWC

[20.102] DPT_HVAC-

Mode

1 Byte

30 Temp.control: HVAC mode (prio-

rity 2)

Input /

Output

RWC

[20.102] DPT_HVAC-

Mode

1 Byte

31 Temp.control: Mode frost/heat pro-

tection activt.

Input /

Output

RWC

[1.1] DPT_Switch 1 Bit

32 Temp.control: Block (On when

value = 1)

Input -WC- [1.1] DPT_Switch 1 Bit

33 Temp.control: Current setpoint Output R-CT [9.1] DPT_-

Value_Temp

2 Bytes

34 Temp.control: Switch. (Heating = 0 |

Cooling = 1)

Input -WC- [1.1] DPT_Switch 1 Bit

35 Temp.control: Setpoint Comfort

heating

Input /

Output

RWC

[9.1] DPT_-

Value_Temp

2 Bytes

36 Temp.control: Setpoint Comfort

heat.(1:+ | 0:-)

Input -WC- [1.1] DPT_Switch 1 Bit

37 Temp.control: Setpoint Comfort

cooling

Input /

Output

RWC

[9.1] DPT_-

Value_Temp

2 Bytes

No Text Function Flags DPT type Size
