13 Transfer protocol

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

7. Transfer protocol

Units:

Temperatures in degrees Celsius

Air humidity in %

Absolute air humidity in g/kg and/or g/m

VOC content in ppm

Variables in %

7.1. List of all communications objects

Abbreviation flags:

C Communication

R Read

WWrite

T Transfer

UUpdate

No Text Function Flags DPT type Size

0 Software version readable R-CT [217.1] DPT_Version 2 Bytes

1 Malfunction temperature/humidity

sensor

Output R-CT [1.1] DPT_Switch 1 Bit

2 VOC sensor malfunction Output R-CT [1.1] DPT_Switch 1 Bit

3 External measured value for tempe-

rature

Input -WC- [9.1] DPT_-

Value_Temp

2 Bytes

4 Internal measured value for tempe-

rature

Output R-CT [9.1] DPT_-

Value_Temp

2 Bytes

5 Total measured value for tempera-

ture

Output R-CT [9.1] DPT_-

Value_Temp

2 Bytes

6 Request min./max. temperature

measured value

Input -WC- [1.17] DPT_Trigger 1 Bit

7 Minimum measured value for tem-

perature

Output R-CT [9.1] DPT_-

Value_Temp

2 Bytes

8 Maximum measured value for tem-

perature

Output R-CT [9.1] DPT_-

Value_Temp

2 Bytes

9 Reset min./max. measured value

for temperature

Input -WC- [1.17] DPT_Trigger 1 Bit

10 Temp. thresholdV 1: Absolute value Input /

Output

RWC

[9.1] DPT_-

Value_Temp

2 Bytes

11 Temp. thresholdV 1: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit

12 Temp. thresholdV 1: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

13 Temp. thresholdV 1: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes
