7 Description
Room Controller KNX Touch One Style • Status: 30.07.2020 • Errors excepted. Subject to technical changes.
* Concerning the accuracy of the measurement, please not chapter
Installation location
Please also take note that the displayed temperature value will be too high temporarily
after a power breakdown.
The product conforms with the provisions of EU directives.
1.2. Maintenance and care
Finger marks on the touch screen are best removed with a damp cloth or a microfiber
cloth. You can wipe the buttons without activating them.
Do not use abrasives / detergents or aggressive cleaners for cleaning.
If there is a power outage, the data you have entered will be saved for around 10 years.
No battery is required for this.
Degree of protection IP 20
Dimensions Display front approx. 181 × 131 (W × H, mm),
mounting depth approx. 8 mm,
concealed box approx. 172 × 122 × 81 (W × H × D, mm)
Weight approx. 765 g
Ambient temperature Operational 0 to +45°C, Storage -30 to +70°C
Ambient humidity 5...95% RH, Avoid condensation
Auxiliary supply 20...32 V DC.
A suitable power pack can be
purchased from Elsner Elektronik.
Auxiliary current at
100% display lighting
190 mA at 24 V DC
Auxiliary current at
0% display lighting
55 mA at 24 V DC
Power consumption For 100 % display lighting: max. 4.6 Watt
For 0 % display lighting: max. 1.5 Watt
Bus current max. 10 mA
Data output KNX +/- Bus connector terminal
Group addresses max. 1024
Assignments max. 1024
Communications objects 447 (Number 1 ... 532)
Temperature measurement
range*
0...+45°C
Resolution (temperature) 0.1°C
Humidity measurement
range
5...95 % RH
Resolution (humidity) 0,1 % RH
Accuracy (humidity) ± 7.5% RH at 5…10% RH
± 4.5% RH at 10…90% RH
± 7.5% RH at 90…95% RH
