6 Description
Room Controller KNX Touch One Style • Status: 30.07.2020 • Errors excepted. Subject to technical changes.
1.1. Field of application
The Room Controller KNX Touch One Style enables control of the KNX building
technology for one room by means of a touch-sensitive display screen. The unit pro-
vides integrated control functions which can also be directly set on the display (auto-
matic). Basic settings are made by the installer in the ETS.
The KNX Touch One Style with integrated indoor sensor (temperature, air humidity)
includes an internal automated operation function for shades (sun/privacy shades) and
room climate control (heating, cooling, ventilation), internal light control as well as bus
functions for time and scene control. 4 binary inputs enable the connection of conven-
tional buttons, switches and window contacts.
Eight universal pages with up to eight functions per page can be created to ensure the
orderly operation and display of the function and object assignments.
For remote control of the drives, one Remo 8 eight-channel wireless remote control
can be used with the KNX Touch One Style.
Functions
• Internal automatic shade controls (protection from the sun/privacy)
• Room climate control (heating, cooling, ventilation)
• Internal lighting control
• Integrated interior sensors (temperature, air humidity)
• Bus functions for time and scene control
• Universal menu to display and operate the function and object assignments
• Bus functions: Actuating variable comparators, multi-function modules
(computers), AND/OR logic
Configuration is made using the KNX software ETS. The product file can be down-
loaded from the Elsner Elektronik website on www.elsner-elektronik.de in the “Ser-
vice” menu.
1.1.1. Scope of delivery
• Central control and operation unit with colour touch-display screen, 5.7 inch
Integrated interior sensors (temperature, air humidity) and
4 binary inputs (e.g. for buttons)
• Data sheet
Accessories (not included in the scope of delivery):
• Radio remote control Remo 8
1.1.2. Technical Data
Housing Glass, plastic
Colour White/grey
Assembly Flush/cavity wall
