43 Parameter setting
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
OR logic
6.13.1. AND logic 1-4 and OR logic outputs 1-4
The same setting options are available for AND and OR logic.
Each logic output may transmit one 1 bit or two 8 bit objects. Determine what the out
put should send if logic = 1 and = 0.
If the output type is a 1-bit object, set the output values for the various conditions.
If the output type is two 8-bit objects, set the type of object and the output values
for the various conditions.
OR logic 1 not active • active
OR logic ... not active • active
OR logic 4 not active • active
1. / 2. / 3. / 4. Input • do not use
- Logic inputs 1...16
- Logic inputs 1...16 inverted
• all switching events that the device
provides (see Connection inputs of the
AND/OR logic)
Output type • a 1-Bit-object
• two 8-bit objects
Output value
if logic = 1
1 • 0
Output value
if logic = 0
1 • 0
Object type • Value (0…255)
• Percent (0…100%)
• Angle (0…360°)
• Scene call-up (0…127)
Output value object A
if logic = 1
0 … 255 / 100% / 360° / 127; 1
Output value object B
if logic = 1
0 … 255 / 100% / 360° / 127; 1
Output value object A
if logic = 0
0 … 255 / 100% / 360° / 127; 0
Output value object B
if logic = 0
0 … 255 / 100% / 360° / 127; 0
