19 Parameter setting
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
6. Parameter setting
6.1. Behaviour on power failure/ restoration of
power
Behaviour following a failure of the bus power supply:
The device sends nothing.
Behaviour on bus restoration of power and following programming or reset:
The device sends all outputs according to their send behaviour set in the parameters
with the delays established in the "General settings" parameter block.
6.2. General settings
Set the basic data transfer characteristics and select whether or not malfunction ob-
jects should be sent.
6.3. Temperature value
When measuring temperature, the self-heating of the device is considered by the
electronics. The heating is compensated for in the device.
221 Display lighting (1 = on | 0 = off) Input -WC- [1.1]
DPT_Switch
1 Bit
222 Display lighting brightness Input RWCT [5.1]
DPT_Scaling
1 Byte
223 Display lighting switch-off delay Input RWCT [7.5]
DPT_TimePeriodSec
2 Bytes
Send delay after power-up and programming for:
Measured values 5 s • ... • 2 h
Threshold values and switching outputs 5 s • ... • 2 h
Controller objects 5 s • 10 s • ... • 2 h
Logic outputs 5 s • 10 s • ... • 2 h
Maximum telegram quota • 1 message per second
• ...
• 5 messages per second
• ...
• 20 messages per second
Use temp./humidity malfunction object Yes • No
No Name Function Flags Data Point Type Size
