18 Transfer protocol
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
234 8-bit object 3 for display Input -WC- [5]
5.xxx
1 Byte
235 16-bit object 1 for display Input -WC- [9]
9.xxx
2 Bytes
236 16-bit object 2 for display Input -WC- [9]
9.xxx
2 Bytes
237 Text message 1 for display Input -WC- [16.0]
DPT_String_ASCII
14
Bytes
238 Text message 2 for display Input -WC- [16.0]
DPT_String_ASCII
14
Bytes
239 Display_Return approval Input -WC- [1.1]
DPT_Switch
1 Bit
240 Pushbutton 1 long-term Output R-CT [1.8]
DPT_UpDown
1 Bit
241 Pushbutton 1 short-term Output R-CT [1.10]
DPT_Start
1 Bit
242 Pushbutton 1 switching Input/
Output
R-CT [1.1]
DPT_Switch
1 Bit
243 Pushbutton 1 Relative dimming Input/
Output
RWCT [3.7]
DPT_Control_Dim-
ming
4 Bit
244 Pushbutton 1 encoder 8 bit Output R-CT [5]
5.xxx
1 Byte
245 Pushbutton 1 encoder 16 bit Output R-CT [9]
9.xxx
2 Bytes
246 Pushbutton 1 Scenario Output R-CT [5]
5.xxx
1 Byte
247 Pushbutton 2 long-term Output R-CT [1.8]
DPT_UpDown
1 Bit
248 Pushbutton 2 short-term Output R-CT [1.10]
DPT_Start
1 Bit
249 Pushbutton 2 switching Input/
Output
R-CT [1.1]
DPT_Switch
1 Bit
250 Pushbutton 2 Relative dimming Input/
Output
RWCT [3.7]
DPT_Control_Dim-
ming
4 Bit
251 Pushbutton 2 encoder 8 bit Output R-CT [5]
5.xxx
1 Byte
252 Pushbutton 2 encoder 16 bit Output R-CT [9]
9.xxx
2 Bytes
253 Pushbutton 2 Scenario Output R-CT [5]
5.xxx
1 Byte
No Name Function Flags Data Point Type Size
