Je bekijkt pagina 13 van 58
11 Transfer protocol
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
15 Temp. threshold value 1:
Switching output block
Input -WC- [1.2]
DPT_Bool
1 Bit
16 Temp. threshold value 2: Absolute
value
Input/
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
17 Temp. threshold value 2: (1:+ | 0:-) Input -WC- [1.2]
DPT_Bool
1 Bit
18 Temp. threshold value 2:
Switching delay from 0 to 1
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
19 Temp. threshold value 2:
Switching delay from 1 to 0
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
20 Temp. threshold value 2: Switching
output
Output R-CT [1.1]
DPT_Switch
1 Bit
21 Temp. threshold value 2:
Switching output block
Input -WC- [1.2]
DPT_Bool
1 Bit
22 Temp. threshold value 3: Absolute
value
Input/
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
23 Temp. threshold value 3: (1:+ | 0:-) Input -WC- [1.2]
DPT_Bool
1 Bit
24 Temp. threshold value 3:
Switching delay from 0 to 1
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
25 Temp. threshold value 3:
Switching delay from 1 to 0
Input -WC- [9.010]
DPT_Value_Time
2 Bytes
26 Temp. threshold value 3: Switching
output
Output R-CT [1.1]
DPT_Switch
1 Bit
27 Temp. threshold value 3:
Switching output block
Input -WC- [1.2]
DPT_Bool
1 Bit
29 TR_1_ Eco-Standby HVAC 1 Input -WC- [20.102]
DPT_HVACMode
1 Byte
30 TR_1_ Comfort Activation HVAC 2 Input RWCT [20.102]
DPT_HVACMode
1 Byte
31 TR_1_ Frost/Heat activation Input RWCT [1.1]
DPT_Switch
1 Bit
32 TR_1_ Blocking object (active at
value = 1)
Input -WC- [1.1]
DPT_Switch
1 Bit
33 TR_1_ Target value, current Output R-CT [9.1]
DPT_Value_Temp
2 Bytes
34 TR_1_ Switching object (0:Heat |
1:Cool)
Input -WC- [1.1]
DPT_Switch
1 Bit
35 TR_1_ Target value, comfort heat-
ing
Input/
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
36 TR_1_ Target value, comfort heat-
ing (1:+ | 0:-)
Input -WC- [1.1]
DPT_Switch
1 Bit
37 TR_1_ Target value, comfort cool-
ing
Input/
Output
RWCT [9.1]
DPT_Value_Temp
2 Bytes
No Name Function Flags Data Point Type Size
