43 System settings via ETS
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
The screen saver may be modified via objects no 17 "screen saver" and no. 18 "image
selection from SD card" via the bus. The object no. 17 is input and output
simultaneously, and thus may both receive a command or transmit the status to the
bus autonomously.
The images for the screen saver are loaded from the SD card. The individual images
must be saved to a folder called "diafix", and the images for a slide show in a folder
called "diashow". Please refer to the chapter
Screen saver, Page 59
2.5. Ambient lighting
The Display Corlo Touch KNX has LEDs installed which are directed to the side from
behind the frame. This ambient lighting can be adjusted in terms of colour and
brightness. Settings may be made via objects, on the display or on the ETS menu.
ETS: ambient lighting
Object control
For the settings via objects, i.e. via the bus, objects 22-26 are available.
The ambient lighting objects may be activated in the ETS. The following parameter
only appears when the objects are used ("yes").
Adaptation on the display
The settings on the display are modified via the menu
Settings > system > ambient lighting
and can be secured with an access code (set up in the ETS).
System settings via touch display > Ambient lighting, Page 44
Modification via ETS
Select "Transmit the following parameters: Yes" to render the modifications valid.
Previous settings are then overwritten - including modifications done on the display!
Screen saver type • Screen OFF
• Analogue clock
• Digital clock
• Image from SD Card
• Slide show from SD Card
(start) image number
Object no. 18 "Image selection from SD
card"
[1...65000; 1]
Use objects for ambient lighting • No
• Yes
RGB shares are set via • an object (1x 3 byte, DTP 232.600)
• three objects (3x 1 byte, DTP 5.001)
