144 Additional settings (ETS)
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
Activate the required logic outputs.
AND Logic:
OR Logic:
6.4.1. AND logic outputs 1/2/3/4 and OR logic
outputs 1/2/3/4
The same setting options are available for AND and OR logic.
Each logic output may transmit one 1 bit or two 8 bit objects. Determine what the out
put should send if logic = 1 and = 0.
Logic output transmits a 1 bit object:
Logic output transmits two 8 bit objects:
Example: Objects for shading control
Object A: Shade position Height (0 = safe position, 255 = fully extended).
Object B: Shade position slat angle (255 = 100% closed, 200 = approx. 80% closed).
AND logic output 1...4 Not active • Active
OR logic output 1...4 Not active • Active
1. / 2. / 3. / 4. Input • Do not use
- Logic inputs 1...16
- Logic inputs 1...16 inverted
Logic output transmits • one 1-bit object
• two 8-bit objects
Logic output transmits a 1-bit object
if logic = 1 object value 1 • 0
if logic = 0 object value 1 • 0
Logic output transmits two 8-bit objects
Object type • Value [0…255]
• Percent [0…100%]
• Angle [0…360°]
• Scene call-up [0…127]
if logic = 1 object A value 0 … 255 / 100% / 360° / 127; 1
if logic = 0 object A value 0 … 255 / 100% / 360° / 127; 0
if logic = 1 object B value 0 … 255 / 100% / 360° / 127; 1
if logic = 0 object B value 0 … 255 / 100% / 360° / 127; 0
