119 Automatic functions
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
The supply temperature block closes the window if it is warmer outside than inside.
Select the periods for night-time re-cooling. Activate and define periods you would
like to use here in the "weekly timer" menu first!
The night-time re-cooling is set in the "Automation" menu.
Night-time re-cooling, Page 105
The effect of the outdoor temperature block is that the window remains in the
current position. The block can, for example, be used if the window should not be used
for ventilation in winter (cold protection for plants).
The outdoor temperature block only applies to automatic operation; no ventilation
then takes place. When the rain or wind alarm is triggered, the window will be closed
despite the outdoor temperature block (alarm has priority over blocking temperature).
Manual operation continues to remain possible, even when the window is blocked
because of low outdoor temperatures.
Select the periods during which the window should be opened and those when it
should be closed. Activate and define periods you would like to use here in the "weekly
timer" menu first!
Weekly timer, Page 47
Open from (in % rH)
only if ventilation based on air humidity
(Hysteresis = 3%)
10...95; 60
Use CO
2
No • Yes
Open from above (in 10 ppm)
only if ventilation based on CO
2
value
50...200; 80
Close from below (in 10 ppm)
only if ventilation based on CO
2
value
50...200; 55
Close the window when the supply air
temp. is higher than the room temperature
No • Yes
Use night-time re-cooling for
Period 1 - 16 No • Yes
Open window until room temperature
falls below below (in 0.1°C)
50...500; 160
Window opening (in %) 0...100; 30
Use outdoor temperature block No • Yes
Close when below (in 0.1°C)
if temperature block is used
-100...200; 50
Use time opening for
Period 1 - 16 No • Yes
