10 Description
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
The product conforms with the provisions of EU guidelines.
1.1.3. Customizing options
Colors for edge and frame
The standard colors for the display edge and matching frame are chrome matt and
chrome glossy, white matt and black matt. Special paints are possible, e. g. to RAL
or automobile paint color codes. Please ask for your desired color.
The glass pane is only available with white or black painting, special colours are not
possible.
Bus current approx. 10 mA
Power consumption
Corlo Touch KNX
• approx. 1.3 W maximum (when ambient and logo
lighting 100% white, display brightness 100%)
• approx. 0.9 W in normal operation (when ambient and
logo lighting off, display brightness 50%)
• approx. 0.6 W in standby operation (when ambient
and logo lighting off, display off)
(was measured with 24 V auxiliary voltage)
Power consumption
Corlo Touch KNX WL
• approx. 3.5 W maximum (when ambient and logo
lighting 100% white, display brightness 100%)
• approx. 1.9 W in normal operation (when ambient and
logo lighting off, display brightness 50%)
• approx. 1.7 W in standby operation (when ambient
and logo lighting off, display off)
(was measured with 24 V auxiliary voltage)
Data output/
bus communication
KNX +/- Bus connector terminal
Group addresses max. 1024
Assignments max. 1024
Communication objects 1022
Other data interfaces Micro SD, USB
Browser QT Webkit
Inputs 4× Analogue/Digital,
max. cable length 10 m
Setting range of temperature
sensor T-NTC at input of
Corlo Touch
-40°C...+80°C
Supported WLAN Standards
Corlo Touch KNX WL
IEEE802.11b/g/n, 2.4 GHz
Supported WLAN Security
Corlo Touch KNX WL
64/128-bit WEP, WPA-PSK, WPA2-PSK
