9 Description
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
1.1.1. Deliverables
• Display unit
• Connection line
You will also require (not included in deliverables):
• Corlo frame (available as a single, dual, or triple frame)
Optional accessories:
(not included in the deliverables):
• T-NTC temperature sensor (No. 30516)
• Micro SD card for image data (off the shelf)
1.1.2. Technical data
Housing Glass: real glass, tempered
Edge: zinc pressure die casting
Housing: plastic
Display Visible diagonal: 3,5 inches
Resolution: 320 × 240 pixel
Viewing Angle: 6 o’clock viewing direction
Opening angle x: -75° to +75° typ.
Opening angle y: -55° to +75° typ.
Colors • White glass, chromed glossy edge
• White glass, chromed matt edge
• Black glass, chromed glossy edge
• Black glass, chromed matt edge
• White glass, white matt edge
• Black glass, black matt edge
• Custom colours on request (see
Colors for edge and frame, Page 10)
Assembly on device socket according to DIN 49073
Degree of protection IP20
Dimensions Housing overall approx. 80 × 71 × 49 (W × H × D, mm),
Mounting depth approx. 12.5 mm
Weight display unit
Corlo Touch KNX
approx. 140 g
Weight display unit
Corlo Touch KNX WL
approx. 160 g
Weight frame frame 1-gang approx. 75 g,
frame 2-gang approx. 95 g,
frame 3-gang approx. 115 g
Ambient temperature Operation 0...+50°C, storage -10...+50°C
Ambient humidity 5...95% RH, avoid condensation
Operating voltage 21,6…26,4 V DC.
A suitable power pack can be purchased from Elsner
Elektronik.
