76 Set up display screens
Display Corlo Touch KNX 5in • Status: 30.08.2021 • Technical changes and errors reserved.
Then assign the function of the area, enter other text you wish to be displayed if
necessary and select a symbol. If you do not wish to display a symbol, select symbol
no. 254 (not assigned).
Symbol overview, Page 87
Area functions
no function
Display 1 / 0
Display date
Display time
Display 8-bit value (0 ... 255)
Display 8-bit value (0 ... 100%)
Display 8-bit value (0 ... 360°)
Display 16-bit counter without math. symbol
Display 16-bit counter with math. symbol
Display 16-bit floating point
Display 32-bit counter without math. symbol
Display 32-bit counter with math. symbol
Display 32-bit floating point
Display text
Display energy [DPT 29.01X]
Input 1
Input 0
Press enter = 1, release = 0
Press enter = 0, release = 1
Input switch
Input date
Input time
Input 8-bit value scene
Input 8-bit value (0 ... 255)
Input 8-bit value (0 ... 100%)
Input 8-bit value (0 ... 360°)
Input 16-bit counter without math. symbol
Input 16-bit counter with math. symbol
Input 16-bit floating point
Input 32-bit counter without math. symbol
Name
Languages 1...6 [free text]
Function see below Area functions
Text(s)
Languages 1...6 [free text]
Key symbol(s) • no symbol
• symbol 1
...254 (internal library, see
table Symbol overview, Page 87)
• image selection (from SD card, see
Exchanging images and graphics, Page 18
