51 System settings via touch display

Display Corlo Touch KNX 5in • Status: 30.08.2021 • Technical changes and errors reserved.

Scroll to the desired setting using the arrow keys on the rocker.

Confirm with OK to save and return to the previous menu selection.

Or cancel using the skip back arrow or the house button .

2.8. Timer

16 periods may be defined on the timer of the Corlo Touch KNX 5in. Those periods

are then allocated to the internal automatic functions such as, e.g. the timed closure of

blinds.

Periods must be pre-set in the ETC menu "weekly timer: period". Periods configured

as outputs may also be modified on the display. Periods configured as inputs only

receive the time settings from another time in the bus system. Only the name of the

input periods is displayed, it is not possible to modify the settings.

Periods may be viewed or modified in the menu

 Settings > system > timer

The menu can be secured with an access code.

 Access codes for display menus, Page 36

Select the symbol to be displayed in case of

alarm. All the icons of the system are

available.

 Symbol overview, Page 91

Additionally, custom symbols may be saved

on the SD card and then loaded. For further

information please refer to chapter

 Exchanging images and graphics, Page 18
