78 Setting the parameters and functions for all
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
* For further details about settings, please see “Control modes for drive control”
auf Seite 79
Input as dimmer:
If the input is used as a dimmer, select the bus function "Dimmer" and specify the but-
ton function, time interval (switching/dimming) and if requested, the repeat interval for
a long button press.
Input 8 bit encoder:
If the input is to be used as an 8bit encoder, select the "8 bit encoder" bus function and
specify which value will be sent.
Input 16 bit encoder:
If the input is to be used as a 16bit encoder, select the "16 bit encoder" bus function and
specify which value will be sent.
Input for scenario control:
If the input is to be used for recalling and saving a scene, select the bus function "scene
call-up" and decide whether the button should be used to save the scene as well (keep
pressed for longer).
Function Dimmer
Button function brighter • darker • brighter/darker
Time between switching and dimming
(in 0.1 s)
1...50; 5
Repeat the dimm command no • yes
Repeat the dimm command
for a long button press
(if dimm command is repeated)
every 0.1 s • every 2 sec; every 0,5 sec
Dim by
(if dimm command is repeated)
1,50% • 3% • 6 % • 12,50% • 25% • 50%
Bus function 8 bit encoder
Value -6707600...6707600; 0
Function 16 bit encoder
Value in 0.1 -6707600...6707600; 0
Bus function Scenario recall
Scenario no. 0...63
Scenario function • Activate
• Activate and save
Press key for longer than (in 0.1 s)
Scenario saving
only for saving
1...50
