76 Setting the parameters and functions for all
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
CO2 controller ventilation 2 active
CO2 controller ventilation 2 inactive
6.8.3. Connection inputs of the OR logic
The OR logic connection inputs correspond to those of the AND logic. In addition the
following inputs are available for the OR logic:
Switching output AND logic 1
Switching output AND logic 1 inverted
Switching output AND logic 2
Switching output AND logic 2 inverted
Switching output AND logic 3
Switching output AND logic 3 inverted
Switching output AND logic 4
Switching output AND logic 4 inverted
Switching output AND logic 5
Switching output AND logic 5 inverted
Switching output AND logic 6
Switching output AND logic 6 inverted
Switching output AND logic 7
Switching output AND logic 7 inverted
Switching output AND logic 8
Switching output AND logic 8 inverted
6.9. Inputs
Mechanical buttons or temperature sensors T-NRC (Elsner Elektronik item number
30516) can be attached to the four analogue/digital inputs of the Cala Touch KNX.
Activate the inputs you want to use.
6.9.1. Input 1-4
Choose a function:
Use input 1 / 2 / 3 / 4 No • Yes
Bus function • Switch
• Changeover switch
• Shutter
• Blinds
• Awning
• Window
• Dimmer
• 8-bit encoder
• 16-bit encoder
• Scene activation / scene saving
• Temperature sensor NTC
