64 Setting the parameters and functions for all
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
General HCL settings
The HCL control is interrupted when a change to manual (with switching, brightness
or color temperature) is carried out via the objects 86-88. These objects can be linked
with switching commands from on-site buttons for example. Also the HCL control
menu of the display can be used to switch to manual.
Set the automatic reset, which ensures that the HCL control is restarted. The reset can
be triggered via an object or after the expiration of the time set here.
Set the behavior of the start / stop object, which indicates whether the HCL control is
active or not. And set the behavior of the object, which indicates whether the automatic
is running or has been interrupted by manual intervention.
Set whether or in which cases times, brightnesses and color temperatures changed on
the display should be saved. And determine from which change on brightness and
color temperature are sent and thus the change should take effect.
Sequence 1/2/3/4/5/6/7/8
Set as many sequences as you need. With the same start and stop times (eg 0:00
o'clock - 0:00 o'clock) the sequence is skipped. The sequence 1 starts with the stop val-
ues of the sequence 8, therefore the values of the sequence 8 should always be set. Se-
quences 2-8 always begin with the stop value of the previous sequence.
Reset of automatic takes place • according to time
• on receipt of object
• on receipt of object or according to time
Reset at value
(on reset on receipt of object)
0 • 1
Time in seconds
(on reset according time)
1 ... 36000; 3600
Start/Stop object is at value • 1 = start | 0 = stop
• 0 = start | 1 = stop
Start/Stop object value after reset 0 • 1
Automatic/Manual status object is at value • 1 = automatic | 0 = manual
• 0 = manual | 1 = automatic
Automatic/Manual object value after reset 0 • 1
Changed times, brightnesses and color
temperatures
shall be saved
• not
• after power supply restoration
• after power supply restoration and pro-
gramming
Send brightness values in case of change
from
1...50%; 5
Send color temperature values in case of
change from
1...500 K; 50
