34 Transfer protocol
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
36 Light 1 brightness Input/
Output
RWCT [5.1] DPT_Scaling 1 byte
37 Switch Light 2 on/off Input/
Output
RWCT [1.1] DPT_Switch 1 bit
38 Dim Light 2 Output R-CT [3.7] DPT_Con-
trol_Dimming
4 bit
39 Light 2 brightness Input/
Output
RWCT [5.1] DPT_Scaling 1 byte
40 Switch Light 3 on/off Input/
Output
RWCT [1.1] DPT_Switch 1 bit
41 Dim Light 3 Output R-CT [3.7] DPT_Con-
trol_Dimming
4 bit
42 Light 3 brightness Input/
Output
RWCT [5.1] DPT_Scaling 1 byte
44 Drive 1 long-term Output --CT [1.8] DPT_Up-
Down
1 bit
45 Drive 1 short-term Output --CT [1.8] DPT_Up-
Down
1 bit
46 Drive 1 movement position Input/
Output
RWCT [5.1] DPT_Scaling 1 byte
47 Drive 1 slat position Input -WCT [5.1] DPT_Scaling 1 byte
48 Drive 1 operation lock Input -WC- [1.1] DPT_Switch 1 bit
49 Drive 2 long-term Output --CT [1.8] DPT_Up-
Down
1 bit
50 Drive 2 short-term Output --CT [1.8] DPT_Up-
Down
1 bit
51 Drive 2 movement position Input/
Output
RWCT [5.1] DPT_Scaling 1 byte
52 Drive 2 slat position Input -WCT [5.1] DPT_Scaling 1 byte
53 Drive 4 operation lock Input -WC- [1.1] DPT_Switch 1 bit
54 Drive 3 long-term Output --CT [1.8] DPT_Up-
Down
1 bit
55 Drive 3 short-term Output --CT [1.8] DPT_Up-
Down
1 bit
56 Drive 3 movement position Input /
Output
RWCT [5.1] DPT_Scaling 1 byte
57 Drive 3 slat position Input -WCT [5.1] DPT_Scaling 1 byte
58 Drive 3 operation lock Input -WC- [1.1] DPT_Switch 1 bit
60 Scene 1 Output R-CT [18.1] DPT_Scene-
Control
1 byte
61 Scene 1 Status Input -WC- [5.10] DPT_-
Value_1_Ucount
1 byte
62 Scene 2 Output R-CT [18.1] DPT_Scene-
Control
1 byte
No. Text Function Flags DPT type Size
