25 Operating the device via the touch display
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
The page is only displayed if the "Universal display" has been activated in the ETS set-
ting item "Menus".
Menus, page 57 and Universal display, page 62
The "Unversal display" menu page is divided into four areas, each of which can be used
to display values.
(1) name
(2) display area with individual labeling
(3) value
(4) unit
The universal menu serves as a pure display / information page, not for the operation
of functions.
The basic setup of the universal menu is done in the ETS.
Universal display, page 62
(5) The dots on the lower display edge symbolise the individual menu pages in the
main menus. The currently selected position is marked in colour. Swipe to the left or
right on the display to show the other menu pages.
4.9. RGB control
On the "RGB control" operating page, the color of an RGB light can be individually ad-
justed.
Manual setting of a RGB color value on the device is only possible if the "RGB control"
has been activated in the ETS setting item "Menus".
Menus, page 57 and RGB control, page 62
1
Fig. 18: Menu Üniversal display
2
5
3
4
