20 Operating the device via the touch display
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
Switching over an On/Off area
If Switching via an area On/Off has been selected, the display shows:
(1) name
(2) area with the selected symbol
The symbol is grey when switched off, and blue when on.
The area switches between on and off. If dimming is set in addition, touch the area for
longer to dim. This process is shown by repeated dimming of the symbol. When dim-
ming, any new contact also switches, i.e. the dimming increases in brightness or de-
creases alternately.
(3) The dots on the lower display edge symbolise the individual menu pages in the
main menus. The currently selected position is marked in colour. Swipe to the left or
right in this area to show the other menu pages.
1
3
Fig. 13: Light menu, an area
2
Light bulb symbol Touch area (marked
in red)
Light switch (tap or
touch for longer to
dim)
Symbol
Circle
