23 Setting the parameters

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

If the comfort setpoint value is used as a basis:

If the comfort setpoint is used as the basis, the increase/decrease of this value is indi-

cated.

Setpoint values for frost/heat protection (building protection)

The building protection mode is used, for example, as long as windows are open for

ventilation. Setpoints for frost protection (heating) and heat protection (cooling) are

determined which may not be modified from outside (no access via operating devices

etc.). The building protection mode may be activated with delay, which allows you to

leave the building before the controls switch to frost/heat protection mode.

General variables

This setting appears for the control types "Heating and Cooling" only. This is where you

can decide whether to use a common variable for heating and cooling. If the 2nd stage

has a common variable, this is also where you determine the control mode of the 2nd

stage.

When using the variable for a 4/6 way valve:

0%...100% Heating = 66%...100% variable

OFF = 50% variable

0%...100% Cooling = 33%...0% variable

Max. object value heating/cooling (in 0.1

°C)

-300…800; 280

Reduce heating setpoint (in 0.1°C)

(for heating)

0…200; 50

Increase cooling setpoint (in 0.1°C)

(for cooling)

0…200; 60

Nominal value frost protection\r\n(in 0,1°C) -300…800; 70

Activation delay no • 5 s • ... • 5 min • … • 2 h

Nominal value heat protection (in 0,1°C) -300…800; 350

Activation delay no • 5 s • ... • 5 min • … • 2 h

For heating and cooling • separate variables are used

• common variables are used for

Stage 1

• common variables are used for

Stage 2

• common variables are used for

Stage 1+2

Use variable for 4/6-way valve

(only with common variable at stage1)

No • Yes

Control type

(for stage 2 only)

• 2-point-control

• PI control

Regulating variable of the 2nd Stage is on

(only for stage 2 with 2-point control)

• 1-bit object

• 8-bit object
