User Manual: Interactive Digital Signage
SW601990 Rev K, Page 25 of 37
Monitor Size
Thermal
Protection
Mode Step
1 Disabled
(°C)
ET32/4201L 55
ET5501L 53
ET7001L/ET7001LT 45
If Thermal Protection Mode Step 2 is reached, the internal temperature needs to first decrease
back to the Step 1 temperature and then decrease further to the value required to disable
Thermal Protection Mode 1.
Example of Thermal Protection Mode for an ET4201L Monitor with 100% Brightness:
At Step 1: OSD = 60, Brightness = 80%
Normal operation returns if OSD can maintain 55°C or lower temperature for five
minutes.
At Step 2: OSD = 65, Brightness = 72%
Return to Step 1 if OSD can maintain 60°C or lower temperature for five minutes.
If the monitors internal temperature continues to rise, the monitor will shut off at OSD = 70°C
Table Top Mode
Requirements:
1. The Table Top Mode function on the OSD must be enabled if the unit is placed in table
top orientation.
2. Cooling methods must be put in place to ensure that the air temperature beneath the
monitor does not exceed the operating specifications. Consult chapter 7 for operating
temperature specifications.
Note: The warranty will be void if failure occurs to the monitor in table top mode orientation and
the Table Top Mode function is not enabled without adequate cooling methods installed.
When the monitor is in Table top mode, the Thermal Protection steps are different. These OSD
values are stated in the table below.
Monitor Size
Thermal
Protection Mode
Enabled (°C)
Step 1
Thermal
Protection Mode
Enabled (°C)
Step 2
Thermal
Protection Mode
Enabled (°C)
Step 3
Auto Shut Off
Temperature (°C)
ET32/4201L 60 65 70 75
ET5501L 57 61 n/a 65
ET7001L/ET7001LT 59 64 69 74
