32

Moving a design

You can make ne adjustments to the position of the

embroidery design.

Press the angle/move key !1.

The jog keys appear on the screen.

Press the or key u to move the design 0.5 mm right

or left (X window o).

Press the or key i to move the design 0.5 mm

forward or backward (Y window !0).

The moving distance from the original position is shown

as coordinates in the X and Y windows.

Fine position/angle adjustment key

You can make ne adjustments to the position or angle of

the embroidery design without removing the embroidery

hoop from the machine.

Press the ne position/angle adjustment key q.

The original embroidery design position is previewed as

a black rectangle w.

q

Rotating a design

You can make ne adjustments to the angle of the

embroidery design.

Press the key r to rotate the design 0.5 degrees

clockwise.

Press the key t to rotate the design 0.5 degrees

counterclockwise.

The angle value is displayed in the window y.

w

y

!1

t

The red rectangle e appears when you make ne

adjustments to the embroidery design, and it shows the

difference between the original position and the adjusted

position.

e

r

i

o

!0

u

NOTE:

The angle of an embroidery design can be adjusted

from -5.0 to 5.0 degrees.

The angle of the embroidery design cannot be

adjusted to exceed the sewing area.

NOTE:

The position of an embroidery design can be ne

adjusted from -5.0 mm to 5.0 mm.

The position of the embroidery design cannot be

adjusted to exceed the sewing area.

The moving distance from the original position is

shown only in millimeters.
