8
Extra spool pin
Use the extra spool pin when you need to wind a bobbin
without unthreading the machine while working on a
sewing project.
Insert the extra spool pin into the hole as shown.
Place a spool of thread on the extra spool pin and x the
spool with the spool holder.
q
Extra spool pin
w
Hole for extra spool pin
e
Large spool holder
Setting the Spool of Thread
Lift up the spool pin. Place the spool of thread on the
spool pin.
Attach the large spool holder, and press it rmly against
the spool of thread.
Winding the Bobbin
Removing the bobbin
NOTE:
Use the small spool holder to hold narrow or small
spools of thread.
CAUTION:
Press the lockout key or turn the power switch off.
NOTE:
Use the plastic bobbins for horizontal hook marked with
a “J”
r
. Using other bobbins, such as pre-wound paper
bobbins, may cause stitching problems and/or damage
to the bobbin holder.
x
z
q
w
Use the spool holder (special) to hold the specic size of
the spool of threads as shown.
The sizes of the spools of thread are as follows;
The hole diameter of the spool has a range of 3/8˝ to
7/16˝ (9.5 to 10.5 mm)), and the spool length has a range
of 2 3/4˝ to 3˝ (70 to 75 mm).
q
Spool holder (special)
w
Hole diameter (3/8˝ to 7/16˝)
e
Spool length (2 3/4˝ to 3˝)
Firmly insert the spool holder (special) into the hole and
hold the spool as illustrated.
q
q
w
w
e
Draw the thread to the left and forward around the bobbin
winder thread guide as shown.
Firmly pull the thread to the right.
Follow the procedure from
x
to
,
of page 9 to wind the
bobbin.
r
e
q
w
e
z
Slide the hook cover release button
q
to the right, and
remove the hook cover plate
w
.
q
Hook cover release button
w
Hook cover plate
x
Remove the bobbin
e
from the bobbin holder.
e
Bobbin
