131
Cleaning the Hook Area
Clean the hook area frequently.
z Remove the needle plate (refer to page 33).
Turn the power switch off and unplug the machine.
Remove the needle and presser foot (refer to pages
21 and 23).
Take out the bobbin and bobbin holder.
q Bobbin holder
x Clean the bobbin holder with a lint brush.
Wipe the bobbin holder both inside and outside with a
soft cloth.
w Lint brush
e Soft cloth
c Clean the feed dog, auto thread cutter device and
around the bobbin thread detecting sensor with the lint
brush.
r Feed dog
t Auto thread cutter device
y Bobbin thread detecting sensor
CARE AND MAINTENANCE
WARNING:
Turn the power switch off and unplug the machine
before cleaning.
Do not dismantle the machine in any way other than
as explained in this section.
CAUTION:
Do not store the machine in a high-humidity area,
near a heat radiator, or in direct sunlight. Store the
machine in cool dry place.
Clean the outside of the machine with a soft cloth.
Do not use chemical solvents.
v Clean the hook race with a soft cloth.
u Soft cloth
b Insert the bobbin holder so that the knob ts next to
the stopper in the hook race.
Insert the bobbin.
Attach the needle plate, presser foot and needle.
i Knob
o Stopper
