16
Extra spool pin
Use the extra spool pin when you need to wind a bobbin
without unthreading the machine while working on a
sewing project.
Insert the extra spool pin into the hole as shown.
Place a spool of thread on the extra spool pin and x the
spool with the spool holder.
q Extra spool pin
w Hole for extra spool pin
e Large spool holder
NOTE:
The extra spool pin is also used for twin needle
sewing.
Setting the spool of thread
Lift up the spool pin. Place the spool of thread on the
spool pin.
Attach the large spool holder, and press it rmly against
the spool of thread.
q Large spool holder
Winding the Bobbin
Removing the Bobbin
Slide the hook cover release button to the right, and
remove the hook cover plate.
q Hook cover release button
w Hook cover plate
Lift out the bobbin from the bobbin holder.
e Bobbin
NOTE:
Use the “J” plastic bobbins (marked with “J” r) for
horizontal hook. Using other bobbins, such as pre-
wound paper bobbins, may cause stitching problems
and/ or damage to the bobbin holder.
Use the small spool holder to hold narrow or small spools
of thread.
w Small spool holder
r
q
w
e
e
Use the spool holder (special) to hold the specic size of
the spool of threads as shown.
The sizes of the spools of thread are as follows;
The hole diameter of the spool has a range of 3/8˝ to
7/16˝ (9.5 to 10.5 mm), and the spool length has a range
of 2 3/4˝ to 3˝ (70 to 75 mm).
e Spool holder (special)
r Hole diameter (3/8˝ to 7/16˝)
t Spool length (2 3/4˝ to 3˝)
Firmly insert the spool holder (special) into the hole and
hold the spool as illustrated.
r
r
t
q
w
e
e
q
w
