15
2.3 GaS ConneCtion
Assembly of Gas Supply and Leakage
Check
Connect the appliance in accordance with
applicable local and international standards
and regulations. First, check what type of
gas is installed on the cooker. This
information is available on a sticker on the
back of the cooker. You can find the
information related to appropriate gas
types and appropriate gas injectors in
the technical data table. Check that the
feeding gas pressure matches the values
on the technical data table, to be able to
get the most efficient use and to ensure the
minimum gas consumption. If the pressure
of used gas is different than the values
stated or is not stable in your area, it may
be necessary to assemble an available
pressure regulator on the gas inlet. You
should contact an authorized service
center to make these adjustments.
Points that must be Check During
Flexible Hose Assembly
• If the gas connection is made by a
flexible hose fixed onto the gas inlet of
the hob, it must be fixed on by a pipe
collar.
• Connect your appliance with a short
and durable hose that is as close as
possible to the gas source.
• The permitted maximum length of the
hose is 36 inches (90 cm).
• The device should be connected in line
with the relevant local gas standards.
• The hose must be kept clear of areas
that may heat up to temperatures of
more than 194 ºF (90 ºC).
• The hose must not be cracked, torn,
bent or folded.
• Keep the hose clear of sharp corners
and objects that could move.
• Before you assemble the connection,
you must make sure the hose is not
damaged. Use bubbly water or leakage
fluids to perform the check. Do not use
a naked flame to check for gas leakage.
• All metal items that are used during gas
connection must be free from rust.
Check the
expiration date of any
components used for connection.
Points that must be Check During
Fixed Gas Connection Assembly
This appliance has been tested in
accordance the following standards :
• ANS Z21.1 : Household Cooking
Appliances
• CSA 1.1 : Household Cooking
Appliances
• CAN / CSA-C 22.2 No 61-M89
Household Cooking Ranges
• In Canada : Installation shall be in
accordance with CAN 1-B149.1 and
CAN 1-B149.2 Installation Codes for
Gas Burning Appliances and or local
codes.
• It is the responsibility of the owner and
the installer to determine if additional
requirements, such as local codes
and/or standards, apply to specific
installations. The installation shall
conform with local codes or, in the
absence of local codes, with th National
Fuel Gas Code, ANSI Z223.1/NFPA
54 or, in Canada, the Natural Gas and
Propane Installation Code, CSA B149.1.
• The method used to assemble a fixed gas
connection (gas connection made by
threads, e.g. a nut) varies according to the
country you are in. The most common parts
for your country will be supplied with your
appliance. Any other parts required can be
supplied as spare parts.
• During connection, always keep the nut
on the gas manifold fixed while rotating the
counter-part. Use appropriately-sized
spanners for a safe connection. For
surfaces between different components
always use the seals provided in the gas
conversion kit.
• The seals used during connection should
also be approved to be used in gas
connections. Do not use plumbing seals for
gas connections.
• Remember that this appliance is ready
to be connected to the gas supply in the
country for which it has been produced.
The main country of destination is marked
on the rear cover of the appliance. If you
need to use it in another country, any
of the connections in the figure below
may be required. In such a case, contact
local authorities to learn the correct gas
connection.
Note: Use pipe joint sealant on all male
(outside) pipe threads to stop leaks. When
tightening fittings, avoid allowing the gas
pressure regulator to turn on the pipe.
