APPENDIX A: MACHINES

84

PB (Pitch Bend) controls the pitch bend data sent on the MIDI track.

AT (Aftertouch) controls the aftertouch data sent on the MIDI track.

MW (Mod Wheel) controls the modulation wheel data sent on the MIDI track.

BC (Breath Controller) controls the breath control data sent on the MIDI track.

FLTR PAGE 1

Here you can set the values of the first eight assignable CC commands. The default value of the pa-

rameters on this page is OFF, meaning they are disabled and do not send out any data. Press and hold

[FUNC] and then press the DATA ENTRY knobs to enable them. You can then use the DATA ENTRY

knobs to set the parameter values as usual. Disable the parameters again by repeating the enabling

procedure.

VAL1-VAL8 (CC 1–8 Value) controls the values that the CC commands send. You specify the CC

commands themselves on FLTR page 2. The default value of these parameters is OFF. Press

[FUNC] + DATA ENTRY knobs to activate the parameters and then turn the DATA ENTRY knobs to

set a value.

Here you can also name the parameter whose value you control. Press and hold

[FUNC] and then press and hold any DATA ENTRY knob to access the naming screen.

For more information, please see “6.7 THE NAMING SCREEN” on page 22.

FLTR PAGE 2

Here you select the first eight CC commands whose values you set with the parameters on the FLTR

page 1. Press the corresponding knob or [YES] to activate the CC command change.

SEL1-SEL8 (CC 1–8 Select) specifies the CC commands whose values you control by the param-

eters on the AMP PAGE 1 (CC VALUE) page. The selectable commands are the standard MIDI

Control Change Messages.

AMP PAGE 1

Here you can set the values for eight additional assignable CC commands.

VAL9-VAL16 (CC 9–16 Value) controls the values that the CC commands send. You specify the

CC commands themselves on AMP page 2. The default value of these parameters is OFF. Press

[FUNC] + DATA ENTRY knobs to activate the parameters and then turn the DATA ENTRY knobs to

set a value.

AMP PAGE 2

Here you select the eight additional CC commands whose values you set with the parameters on AMP

page 1. Press the corresponding knob or [YES] to activate the parameter change.

SEL9-SEL16 (CC 9–16 Select) specifies the CC commands whose values you control by the pa-

rameters on the AMP page 1 (CC VALUE) page. The selectable commands are the standard MIDI

Control Change Messages.
