13. BUS TRACK PARAMETERS

60

RTIM

Repeat Time sets the retrig rate. 1/16 is the nominal retrig rate, one trig per step. 1/32 corresponds to two

trigs per step and so on. To do triplets, for example, set the retrig rate to 1/12 (or 1/24).

RVEL

Repeat velocity sets the velocity curve fade-out and fade-in of the retrig. 1 corresponds to a complete

fade out during the set length, 0,5 fades out to half the velocity during the set length, 0 equals a flat

velocity curve with no fade, 0.5 fades into half velocity during the set length, and 1 fades in completely to

full velocity during the set length. Please note that the eects of the VFAD setting is also dependent on

the VEL setting on TRIG PAGE 1.

COND

(Trig Condition) when you add a conditional lock, COND sets the Trig Condition with which a set of con-

ditional rules can be applied to any trig, using a conditional parameter lock. For more information, please

see “10.10.2 TRIG CONDITIONS AND CONDITIONAL LOCKS” on page 41.

13.3 SRC, FLTR, AMP PAGES

These pages are empty unless you have selected a MIDI SRC machine for the bus track. These pages will

then contain the parameters specific to the MIDI machine.. For more information about these parameters,

please see “A.2.4 MIDI” on page 82.

13.4 FX PAGE 1 (TRACK ROUTING)

The FX parameter page 1 contains parameters that set the routing of the track and the send levels from the

track to the Send FX.

SND1–3

Send 1–3 sets the amount of sound sent through to Send FX 1–3. For more information, please see “14.

SEND FX TRACK PARAMETERS” on page 62.

ROUT

Routing selects where to route the audio from the selected track’s Bus. This parameter mirrors the

setting in the ROUTING menu. The routing switches for this parameter are shown with “B” in the sound

architecture illustrations For more information, please see “4. TONVERK SOUND ARCHITECTURE” on

page 17 and “4.4 THE ROUTING MENU” on page 17.

• MIX AB is the default setting and routes the audio to the MIXER and then through the Main FX to the

A/B outputs and the Headphones.

• OUT CD routes the audio directly to the C/D outputs.

• OUT EF routes the audio directly to the E/F (HEADPHONES) outputs.

13.5 FX PAGE 2 (INSERT FX 1/2)

The parameters on the FX page 2 control the audio track’s selected first insert FX machine. Press [FUNC]

+ [FX] to select FX machine. The parameters vary depending on which insert FX machine is selected. For

more information, please see “A.3 FX MACHINES” on page 85.

13.6 FX PAGE 3 (INSERT FX 2/2)

The parameters on the FX page 3 control the audio track’s selected second insert FX machine. Press

[FUNC] + [FX] to select FX machine. The parameters vary depending on which insert FX machine is select-

ed. For more information, please see “A.3 FX MACHINES” on page 85.
