26
Installation manual
8 Electrical connection
8.1 Electrical installation
The electrical installation may only be carried out by qualified personnel.
Machines with frequency-controlled motors can be incompatible with certain types of earth leakage circuit break-
er. It is important to know that the machines are designed to provide a high level of personal safety, which is why
items of external equipment such as earth leakage circuit breakers are not necessary but is recommended. If you
still want to connect your machine across an earth leakage circuit breaker, please remember the following:
• contact a skilled, authorised installation company to ensure that the appropriate type of breaker is chosen and
that the dimensioning is correct
• for maximum reliability, connect only one machine per earth leakage circuit breaker
• it is important that the earth wire is properly connected.
An individual electrical disconnect must be provided in proximity to each machine.
In instances where the machine is not equipped with an omni-polar switch, one must be installed beforehand.
Mount a multi-pole switch prior to the machine to facilitate installation and service operations.
The connecting cable shall hang in a gentle curve.
When connecting to a terminal block, the connection cable shell must be stripped 10-11 mm / 3/8 — 7/16 inch. The
cable area must be at least 0.5 mm
2
/ 0.0008 inch
2
and no more than 4 mm
2
/ 0.006 inch
2
(AWG12/AWG20). The ter-
minal block used is a spring loaded cage clamp.
8.2 Electrical connections
EUD-615
Electrical connections
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended
fuse
ITCB A
Electric heated 208-240V 1~ 60 2.0/3.0 5.2/3.4 15/20
208-240V 1~ 60 5.4/7.5 5.7/7.8 30/50
208-240V 3~ 60 2.0/3.0 5.2/3.4 15/15
208-240V 3~ 60 5.4/7.5 5.7/7.8 20/25
440V 3~ 60 5.4/7.5 5.7/7.8 15/15
480V 3~ 60 5.4/7.5 5.7/7.8 15/15
Non heated/Steam heated 120/440/480 1/3~ 60
1
1.0 15
208-240V 1~ 60
1
0.9 15
1. Total power and recommended fuse does not depend on the heating power in those cases.
