12
Installation manual
5.2.1 Draft stabilizer
The drying cabinet has been tested and set at factory for connection with a draft stabilizer. (Kit for this included upon
delivery.)
Place the spigot (A) over the hole in the top of the cabinet. Insert the screws and secure the spigot.
A
fig.W01510
Connect the flexible hose (B) to the spigot. Connect the other end of the hose to the draft stabilizer (C), and then
press the draft stabilizer securely into the exhaust air vent in the room.
C
1
2
B
3
4
fig.W01511
1 Humid air out
2 Ventilation from the room
3 Nipple
4 Air intake
