26 en | Amplifier DSP ZLX-G2 Full-range loudspeaker
2024-03 | 02 |
User manual
Bosch Security Systems, LLC
3. Slowly turn up the output of the loudspeaker, and begin sound checking your
microphone or instrument.
4. As you hear feedback, allow a few seconds for the automatic feedback suppression
(AFS) to detect and to reduce the feedback.
5. Continue sound check until no additional feedback tones are generated.
MIX OUT menu
The MIX OUT menu is used to select which signal(s) should be output at MIX OUT and
which signal should be delivered by the loudspeaker.
– L+R - The left and right signals of all inputs are summed. The sum is output at MIX OUT
and is delivered by the loudspeaker (default).
– L - Only the panned left signal of all inputs is output at MIX OUT. The loudspeaker will
deliver only the right signal.
– R - Only the panned right signal of all inputs is output at MIX OUT. The loudspeaker
will deliver only the left signal.
BLUETOOTH menu
The BLUETOOTH menu is used to set the Bluetooth® functionality of the loudspeaker.
ON/OFF - The ON/OFF menu controls whether Bluetooth® functionality is enabled or
disabled on the loudspeaker.
CONTROL PAIR - The CONTROL PAIR menu is used to enable the QuickSmart Mobile app
wireless control and monitoring application. Available options for this selection are: ON or
OFF.
The default is OFF.
AUDIO PAIR - The AUDIO PAIR menu is used to stream audio from your Bluetooth® enabled
device to the loudspeaker system. Available options for this selection are: PAIRING, ON or
OFF.
The default is OFF.
LINKSPEAKERS
The LINKSPEAKERS function allows two ZLX-G2 loudspeakers to be linked over Bluetooth®
in true wireless stereo for Bluetooth® audio streaming only.
To link two ZLX-G2 loudspeakers:
1. Pair one of the ZLX-G2 loudspeakers via Bluetooth® to a mobile device. Refer to Pairing
the QuickSmart Mobile app, page 14 for pairing instructions.
2. In both ZLX-G2 loudspeakers, navigate to the BLUETOOTH menu in the Main DSP
menu.
3. In both ZLX-G2 loudspeakers, select LINKSPEAKERS.
The LCD display will show LINKINGSPEAKERS... while establishing connection
between both ZLX-G2 loudspeakers. When the connection is established, the menu will
display UNLINKSPEAKERS.
In the BLUETOOTH menu below the LINKING SPEAKERS, the stereo channel selection
will appear.
4. Select the appropriate stereo channel selection for each ZLX-G2 loudspeaker: L+R
(mono), L, or R.
Note: This is stereo image from the audience's perspective, also known as House L & R.
