30 en | Rigging system EVA Expandable Vertical Array
2023-01 | 04 | F01U196199
Installation manual
Electro-Voice
2. Using four M10 flathead screws (supplied), attach a tie plate (flat end to the rear) to each
end of the suspended module. Do not fully tighten the screws.
3. Move the second module into place under the suspended module between the tie plates.
4. Align the holes in the tie plates with the corresponding holes in the lower module and
assemble the module to the one above with four M10 flathead screws (supplied).
5. Fully tighten all eight M10 screws.
6. Connect the input terminals of the uppermost full-range module in parallel with the EVA
full-range modules below it.
i
Notice!
Subwoofer modules require a dedicated amplifier channel and may need individual wiring
according to their combined impedance and the drive capabilities of the amplifier.
7. Repeat steps 1 through 6 to attach additional EVA modules.
!
Warning!
To prevent audible air leaks, install a pair of M10 screws per end panel of the last module
where the tie plate would attach.
To complete the EVA array:
1. Using the supplied M5 screws, attach the cosmetic end panels.
2. Tighten the screws by hand or use a power drill with a moderate torque setting.
Do not overtighten. Overtightening drives the screws through the wood of the end panels.
i
Notice!
An array is typically fed from the top down. Wire each module to the module above (except
for subwoofer modules), and set and verify the shading selector position per PREVIEW
Loudspeaker Software.
3. If needed, install attenuation modules.
!
Warning!
Shading and/or attenuation in the wrong place seriously detracts from the performance of the
completed array.
4. Hoist the completed array into position and secure it in the final way intended.
