8
3.
Set up your MIDI master device to control MIDI CC #24. CC #24 controls the
RATE slider on the 8-STEP.
4.
Send out a range of values on CC #24 from 0 to 127. As the values increase, the
RATE will increase on the 8-STEP.
5.
Now set your MIDI device to output MIDI Program Change #100, this may be
#101 on some devices.
6.
Send MIDI PC #100. When you do the 8-STEP will immediately begin playback,
as if you had pressed the PLAY FSW on the unit. Send PC #100 again to pause
playback.
7.
Check the MIDI chart at the end of this manual for a complete list of all of the
MIDI command assignments and the parameters they control on the 8-STEP.
Changing the 8-STEP’s MIDI Channel
1.
Press and hold the RESET FSW. After 3 seconds you will see the GL and SL LEDs
blink, while the DIR LED is off. At this point the current MIDI channel is
displayed on the digit display.
2.
While continuing to hold down the RESET FSW, turn the MODE knob clockwise to
increment the MIDI channel and counter-clockwise to decrement the MIDI
channel.
3.
The range of available channels is 1 through 16 plus a setting displayed as
A
where all MIDI channels are recognized. Since there is only one digit available on
the display, the digit’s decimal LED lights up to indicate the tens placeholder. So
Channel 12 is shown by displaying the number 2 plus the decimal LED:
(2.)
.
Channel 2 would be shown by displaying only the number 2
(2)
.
4.
To enable all MIDI channels, turn MODE clockwise past Channel 16. An
A
will be
displayed on the digit, now all MIDI channels are recognized.
5.
Once you have selected your chosen MIDI channel, release the RESET FSW. The
MIDI channel selection remains in memory even after power cycling.
6.
The MIDI channel is a global parameter; it is not saved with presets.
- CONTROLS, INDICATORS & I/O-
The following descriptions detail all of the sliders, knob, switches, LEDs (lights) and I/O jacks
on the 8-STEP PROGRAM:
STEP 1-8 SLIDERS & LEDS
8-STEP’s sequences are composed of up to 8 Steps. Each step has its own independent slider
for setting the expression or CV level. As you push a step slider upward, its output level
increases. When used as an expression pedal replacement, the maximum and minimum
range of each step is equal to the toe (maximum) and heel (minimum) range of an expression
pedal. When the 8-STEP is used as a CV sequencer, the output range is 0V (minimum) to 5V
(maximum).
1
8-STEP PROGRAM
Analog Expression/CV Sequencer
Congratulations on your purchase of the Electro-Harmonix 8-STEP PROGRAM. The 8-STEP is
an analog sequencer that connects to the expression pedal input of many different types of
effects pedals, keyboards and other devices. Think of the 8-STEP as replacing your
expression pedal, controlling parameters in a sequential fashion rather than continuously as
you normally do with an expression pedal. Additionally, the 8-STEP can be connected to
devices that have Control Voltage (CV) inputs.
Special Features of the 8-STEP PROGRAM:
•
Sequence length is selectable between 1 and 8 steps
•
Four available Direction Modes: Forward, Reverse, Bounce and Random
•
Depth and Glide of the sequence output is encoder adjustable
•
Tap Tempo Footswitch allows you to set the tempo with your foot and can be
divided down for faster tempos from the same tap tempo
•
Three available Play Modes: Loop, 1-Shot and Step-Thru (Manual)
•
Reset Footswitch instantly resets the sequence back to its beginning
•
Expression In allows external control over Rate, Depth, Glide or Sequence Length
•
Expression In doubles as an External CV Clock input allowing the 8-STEP to be
synced to an external clock
•
MIDI IN jack allows the 8-STEP tempo to be synced to MIDI Clock
•
Full MIDI control over every parameter on the 8-STEP
•
Comes supplied with a TRS cable for expression control. Use a standard ¼” TS
instrument cable for CV control (0-5V)
•
Save and load up to 10 presets. Add the optional 8-STEP FOOT CONTROLLER to
save and load up to 100 presets
WARNING:
Your 8-STEP PROGRAM comes equipped with an Electro-Harmonix
9.6DC-200BI power supply (same as used by Boss® & Ibanez®:
9.6 Volts DC 200mA). The 8-STEP requires 100mA at 9VDC with a center
negative plug. The 8-STEP does not take batteries. Using the wrong adapter
may damage your unit and void the warranty.
