14
FUNCTIONS
POWER
Press “POWER” to turn the unit On or Off
MODE
Press to change between the 4 different modes. The display will show the symbol for the
mode currently selected.
COOLING
Cooling mode defaults to 22°C and will cool the air while sending warm air
outside.
The desired temperature can be adjusted using the increase and decrease
button between 16°C and 30°C. The fan speed can also be adjusted using
the speed button.
DRY
Dry mode will extract moisture from the air, which will be drained outside
using the installed drain pipe. The fan speed cannot be adjusted in dry mode.
FAN
In fan mode the appliance will recirculate the air within the room, and will not
cool or dehumidify. The fan speed can be adjusted using the Speed button.
HEATING
Heating mode defaults to 24°C and will heat the air while sending cool air
outside.
The desired temperature can be adjusted using the increase and decrease
button between 16°C and 30°C. The fan speed can also be adjusted using
the speed button.
SILENT
Silent mode can only be activated from the app or control panel by pressing
the timer and up buttons at the same time. It will only operate in cooling
mode. The fan speed will change to low, and the desired room temperature
will increase by 1°C after 1 hour, and a second 1°C after 2 hours, reducing
the amount of time the compressor operates.
FAN SPEED
Press to change the fan speed between Low, Medium and High. The fan
speed cannot be adjusted in Dry or Sleep modes.
TIMER
The air conditioner contains a 24 hour timer, which can be used to either set a delayed
start, or a set period of operation. The timers cannot be combined, although the app can
be used to program periods of operation.
SHUTDOWN TIMER: While the unit is running press the timer button, the display will
flash “0” 5 times. After the 5
th
flash, use the up and down buttons to adjust the duration
in 1 hout increments between 1 to 24 hours. When the timer has elapsed, the unit will
shutdown automatically.
DELAYED START TIMER: With the unit in standby, press the timer button, the display
will flash “0” 5 times. After the 5
th
flash, use the up and down buttons to adjust the
duration in 1 hout increments between 1 and 24 hours. After the timer has elapsed, the
unit will start up in the same mode with the same settings as when it was turned off.
INCREASE
AND
DECREASE
Used within cooling and heating modes to adjust the desired room temperature.
Also used while setting the timer to adjust the duration.
Press and hold the INCREASE and DECREASE buttons at the same time to change the
display on the control panel between farenheit and Celcius. Note the display on the
remote cannot be changed.
SWING MODE
After machine turns on, press the “SWING” button, louver will swing continuously up and
down; by pressing the button again the movement will stop and the louver remain in that
position. Swing mode can only be adjusted from the remote, and will initially be turned on
by default.
COMPRESSOR
PROTECTION
There is a 3 minutes delay on power on. In order to protect the life of the compressor and
electronic components please do not switch on the unit for at least 5 minutes after you
turned the unit off.
