FEATURES
• 3 Heating Modes
• 2 Power levels – Comfort Mode (2.5kw) and Eco Mode (1.25kw)
• Tempered Glass Panel
• Easy to Read LED Display
• 24 Hour Countdown Timer
• Wi-Fi Enabled with App Control
• Scheduling functionality through the app.
• Remote Control
• Electronic Thermostat with Frost Protection Function
• Double Overheat Protection
• Wall Mountable or Portable Using the Supplied Castors
• Ingress Protection Rating of IP24
PARTS LIST
2 x Legs
+ 4 Castors
Brackets
Wall plugs
Screws ᶲ4x12
Screws ᶲ4x35
X4
X6
X8
X6
SETTING THE UNIT UP FOR USE
The appliance can be wall-mounted using the supplied mounting brackets, or alternatively
can be set up as a portable heater using the supplied legs with castors. It is important that
the unit is only operated if it is wall-mounted or has the castors fitted.
ATTACHING THE LEGS
1. Fit the castors into the legs, ensuring they click into place.
2. Turn the heater upside down and place on a soft surface.
3. Put the leg assembly in position and align the screws (φ4x12) with the 4 holes on the
underside of each leg, and loosely fit.
4. Once all screws are in place, they should be fully tightened.
5. After the installation is complete, turn the heater the right way up.
Leg assembly
