Page 8 of 25
WALL MOUNTING
The heater must be installed at least 15cm from the floor and 50cm from the ceiling.
IMPORTANT: Before drilling, ensure that no wires or pipelines are behind the wall to prevent
damage.
INSTALLATION
1. Measure the distance between the 3 wall-hanging
holes on the rear of the heater.
2. After double-checking the measurements, mark their
position on the wall, using a pencil. We would advise
using a spirit level to ensure all markings are square
and level.
3. Once you are happy with the marks' position, drill 8 mm-diameter holes using a suitable
drill bit.
4. Insert the wall plugs into the holes. Please note that alternative fixings may be required
depending on the wall type. Ask for professional advice if unsure.
5. Fix the 3φ4x35 screws into the wall plugs and leave these protruding around 5-10mm
for the heater to hang onto.
6. Push the heater to the side so that screws move through the channel on the brackets to
secure it in position.
.
.
