14 | ELCO GmbH
Assembly
Operation manual 50.0 | Status 10.2021
The associated documents must be observed for the
specific installation situation.
Planning and installation instructions for flue gas/
exhaust air
5.2.2 Installation room
The installation room must meet the following
requirements:
B The installation room must comply with the effective
applicable laws and regulations (e.g. in Germany,
the ordinance for heat-producing appliances
(Feuerstättenverordnung)).
B The substrate on which the generation unit is to be
installed must be flat, even, solid, dry and load-bearing.
B The minimum ambient temperature is +5 °C.
If the ambient temperature exceeds +30 °C,
the system regulates downwards, at +37 °C the
system switches off. The efficiency reduces as the
temperature increases.
B The system must be protected against frost and the
elements.
The following are not permitted:
B Installation on floating screed.
B Operation of tumble dryers in the same room.
B Storage of explosive or highly flammable materials
(e.g. paper, paints, petrol) within the installation
location.
B Use of aggressive substances (e.g. sprays,
solvents, chlorinated cleaning agents, paints,
adhesives) in the vicinity of the system.
If the system is installed in vaulted cellars or bare
smooth-walled rooms (hard-walled), there is a risk of
noise and sound resonance.
The system must be positioned so that the following
requirements are fulfilled:
B None of the system’s ventilation or extraction
devices may be blocked or closed.
B The emergency stop switch must always be
accessible.
Space requirement (50.0 Standard, 50.0 High
temperature)
a
b
c
L
B
H
L Length (including hoop guard) 2,587 mm
B Width (including hoop guard) 800 mm
H Height 1,959 mm
a Distance from the generation unit –
optimum free space
1,000 mm
b Distance from the generation unit –
minimum free space required
700 mm
c Distance from the generation unit –
free space after clarification and
approval by the manufacturer
500 mm
