Assembly-Hanging the Fan(continued)
22
¨ Lock the light source under the lamp plate
with the screws removed in the first step
¨ Install the light source by unfastening the
screws under the lamp tray.
¨ Connect cables to the fan and light
source
6.Connecting lamp wire
CAUTlON : To reduce the risk of electric
shock. disconnect the electrical circuit to the
fan before installing the light fixture
¨ Install the Lamp shade(H) as shown
7.Install the lamp cover
CAUTlON : Make sure the power is off before
attaching or removing the lamp cover.
WARNING: Allow the lamp cover to cool
completely before removing.
CAUTlON : Do not over tighten the hex nut, over
tightening the hex nut may cause the lamp cover
to break.
5.Install remote control
Canpoy(B)
Mounting
Bracket(A)
Bracket
screws(A1)
¨ Carefully push the Canopy(B) to the bottom
of the Mounting Bracket(A), make two
sliding holes aligned to the two prominent
screws on the Mounting Bracket(A), and
then turn clockwise until tight.
Pantalla de la lámpara(H)
Destornillador
