Operation Guide
7
4.
5. Once set, press the “ Menu” button to confirm the
setting and return to DMX Address mode.
.8:8:8:8
MENU
MENU
MENU
When in Switch Pack mode, there are two options
to choose from- , automatically
switches the power ON regardless of DMX signal or
Switch On (S-on)
activates switch mode via DMX
and the power will switch ON/OFF when the channel
value exceeds 40%. When channel value it less than
40%, channel output will be zero or OFF.
Press the UP/DOWN arrow buttons to select
ON and OFF.
Switch Off (S-of),
1. Press the “Menu” button until the letter “d” or
“S” appear in the left hand side of the display.
Assigning as Dimmer Pack
Assigning as Switch Pack
Rear Panel Overview
1. Power Cord: Plug in
2. Fuse : 10A 250V 5x20mm
same type fuse.
3.
4.
16AWGX3C power cable. to a 120V. supply.
Housing Houses a fuse. Always replace with
DMX Input: 3-pin XLR male socket, used to receive DMX data.
DMX Output: 3-pin XLR female socket, used to send DMX data.
5. Mini input socket: This is to connect the supplied external fader for
external control if desired.
4
234
1
5
Rear Panel
