Recording
In Edit menu, use the F4 fader or Cursor UP/DOWN buttons to select [ACTIVE
EFFECTS].
You can select several fixtures at one time to make a group. Up to 6 groups can be
created. Keep pressing the Fixture button, select the group using F 1-6 buttons
corresponding to the group numbers in the display, its LED lights up. Next select
several equal fixtures, their LEDs will blink simultaneously indicating they are in the
identical group and are active for the show.
Active Effects
esc
ok
[ ]ACTIVE EFFECTS
EDIT MENU
Pressing the right arrow button gives access to this setting. If you have not yet assign
a fixture to be subject to the show, you will be required to select active fixtures or effects.
Select active fixtures/effects
SELECT FIXTURE
Use the Fixture 1-16 buttons to choose the fixture that has been patched in setup
procedure, its LED blinks briefly indicating it is enabled to be subject to the show.
You may select several fixtures at a time, however, only the latest one, whose LED
blinks, is active for the show(it is different from Group described hereinafter). Use
F 1-6 buttons and Pan, Tilt buttons to enable the effects(corresponding to the DMX
channels you assigned in Internal Patch) display in the LCD, their LEDs will light up.
Select active fixtures/effects
COLOR GOBOS G.ROT PRISM SHUTT DIMMR
Select other fixtures to make a group
GPR1 GPR2 GPR3 GPR4 GPR5 GPR6
Always remember the fixture you selected must be the same, or you will be prompted
due to selecting different fixtures.
Select active fixtures/effects
Different fixture: no effect controls
Once this procedure is finished, press the left arrow button to return to the Edit menu.
31
