14
INSTALLATION GUIDELINES
CLAMP INSTALLATION
Alternately, the fixture can be mounted to a truss using mounting clamps secured directly to
the fixture itself. Insert one minimum grade 8.8 steel M12x25mm bolts (not included) into
the mounting hole of each mounting clamp. Please note that TWO (2) MOUNTING CLAMPS
are required to support the fixture safely and securely. Thread each bolt into the match-
ing 12M holes on the underside of the fixture, as shown in the illustration below. Both bolt
must be threaded to a depth of at least 18mm (0.7in) into the fixture base.
Safety
Cable
Loops
Attach
Mounting
Clamp
Here
Safety
Cable
Loops
Attach
Mounting
Clamp
Here
SAFETY CABLE:
ALWAYS ATTACH A SAFETY CABLE WHENEVER INSTALLING THIS FIXTURE
IN A SUSPENDED ENVIRONMENT TO ENSURE THAT THE FIXTURE WILL
NOT FALL IF THE CLAMP FAILS. ONLY USE DESIGNATED RIGGING POINTS
FOR SAFETY CABLE, AND NEVER ATTACH A SAFELY CABLE TO A CARRY-
ING HANDLE.
