Power Spot 250™
©Elation Professionals® Los Angeles, Ca. - wwww.ElationLighting.com - Page 27
4. Operation
Operating Modes: The Power Spot 250™ can operate in three different modes. This next
section will detail the differences in the operating modes.
• Stand alone mode - The fixture will react to sound, chasing through the built-in programs.
• Master/Slave mode - You can daisy chain up to 16 fixtures together to get a synchronized
light show without the need of an external controller. The fixtures will react to sound chasing
to synchronized light show.
• DMX control mode - This function will allow you to control each individual fixtures traits
with a standard DMX-512 controller such as the LSC
® Show Designer 2.
4.1 Universal DMX Control: This function allows you to use a universal DMX-512
controller such as the LSC® DMX Operator II™ or LSC® Show Designer 2™ to control
head movement, the color wheel, the shutter (strobe), and all other DMX traits. A DMX
controller allows you to create unique programs tailored to your individual needs. The
Power Spot 250™ uses 15 DMX channels. See page 27 for detailed description of the
DMX traits.To control your fixture in DMX mode, follow the set-up procedures on pages
13-15 as well as the set-up specifications that are included with your DMX controller.
Use the controller’s faders to control the various DMX fixture traits.This will allow you
to create your own programs.
4.1.1 Follow the instruction on page 18 to set the DMX address.
4.2.2 For longer cable runs (more than a 100 feet) be sure to use a terminator on the
last fixture.
4.2.3 For help operating in DMX mode consult the manual included with your DMX
controller.
4.2 Stand-Alone Operation (Sound Active): This mode allows a single fixture to run to
the beat of the music. Only use this mode when running a single fixture, or when
running several fixtures as individuals.
4.2.1 Mount your fixture in a secure and stable manner.
4.2.2 Access the main menu and select the AUDI function, this will give you access to
the audio submenu. See page 16 for the menu breakdown.
