Je bekijkt pagina 22 van 32
22
DMX CHANNEL FUNCTIONS AND VALUES
ELATION PLATINUM SEVEN™
DMX Channel Values / Functions (40 DMX Channels)
Supports Software Versions: ≥ 1.2.1
Features subject to change without notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
1
1
1
PAN MOVEMENT [8 BIT]
0-255
PAN Movement
2
2
2
PAN FINE MOVEMENT [16 BIT]
0-255
Fine Control of PAN Movement
3
3
3
TILT MOVEMENT [8 BIT]
0-255
TILT Movement
4
4
4
TILT MOVEMENT [16 BIT]
0-255
Fine Control of TILT Movement
5
5
RED [ALL LEDs]
0-255
Red (0-Black - 255-100%)
6
RED FINE [ALL LEDs]
0-255
Red FINE Adjustment
6
7
GREEN [ALL LEDs]
0-255
Green (0-Black - 255-100%)
8
GREEN FINE [ALL LEDs]
0-255
Green FINE Adjustment
7
9
BLUE [ALL LEDs]
0-255
Blue (0-Black - 255-100%)
10
BLUE FINE [ALL LEDs]
0-255
Blue FINE Adjustment
8
11
WHITE [ALL LEDs]
0-255
White (0-Black - 255-100%)
12
WHITE FINE [ALL LEDs]
0-255
White FINE Adjustment
9
13
AMBER [ALL LEDs]
0-255
Amber (0-Black - 255-100%)
14
AMBER FINE [ALL LEDs]
0-255
Amber FINE Adjustment
10
15
CYAN [ALL LEDs]
0-255
Cyan (0-Black - 255-100%)
16
CYAN FINE [ALL LEDs]
0-255
Cyan FINE Adjustment
11
17
VIOLET [ALL LEDs]
0-255
Violet (0-Black - 255-100%)
18
VIOLET FINE [ALL LEDs]
0-255
Violet FINE Adjustment
